Bestolife CBLF-HT Copper Based Drilling Compound

Drilling Compound - Copper Based

BESTOLIFE Cal Bronze Lead Free High Temp (CBLF-HT) is a lead-free, zinc-free compound for rotary-shouldered connections. It provides galling and seizing protection and support for high bearing stress. CBLF-HT applies easily in a wide range of temperatures and conditions, is resistant to washout, and will not harden or bleed excessively in storage.



APPLICATIONS

High temperature compound for drill collars and drill pipe. Recommended for all drilling applications (rotary-shouldered connections) including high temperature environments. It is also effective for use on open gear jack-up legs.



CHARACTERISTICS

Color: Dark Copper
Penetration: 300-320 (ASTM D 217)
Weight/Gallon: 10.2 pounds/gallon
Dropping Point: 500°F/260°C (typ)
Flash Point: 385°F/196°C (min)
Brushable To: 15°F/-9°C
Friction Factor: 1.1 (per API RP 7A1)*
Contains: Copper fake, synthetic and amorphous graphite, and other nonmetallic additives



NOTE:
3 1/2 gallon: 35 pounds plastic container weight
5 gallon: 50 pounds plastic container weight



PRODUCT NUMBER	CONTAINER SIZE	CONTAINER WEIGHT
655235	3 1/2 gallon	35 pounds 15.87 kgs
655250	5 gallon	50 pounds 22.67 kgs
